ElastPro FLEXIBLE TPE EXPANSION JOINT TAPES (For Expansion/Contraction/Construction/Movement Joints)

ElastPro Flexible TPE Expansion Joint Tapes are made of thermoplastic elastomer material laminated with hole punching on both sides, designed specifically to provide insulation and waterproofing of high movement expansion gaps, suitable across various surfaces/substrates, providing water tightness. Highly flexible, root-proof, UV and chemical resistant.These tapes are pasted using 2-Component epoxy adhesives.

1. Waterproofing horizontal and vertical dilatation joints.
2. Waterproofing wide and irregular cracks. Connection joints of slabs and walls.

• Suitable substrates are concrete, mortar, wood, metal, steel, aluminium, epoxy mortar, natural and artificial stones and many other building materials.

ADVANTAGES

Highly flexible TPE material with fleece lamination. Excellent adhesion, easy repairable and rupture resistant. Root-proof, water, weather,UV and chemical resistant.

APPLICATION PROCEDURE

Surfaces must be clean, sound and dry. On damp surfaces the pull off strength should be tested. Dust, oil, grease, old coatings, laitance, efflorescence, rust, curing compounds, wax, formwork release oil and similar contaminants must be removed prior to application. Over Concrete surfaces if necessary the substrate must be sanded to guarantee optimal adhesion of ElastPro Adhesives. Verify the substrate has been properly cured. Concrete should obtain 80% of design strength, typically achieved within 3-14 days. Irregularities on the substrate must be repaired.

1. ElastPro Adhesives is applied to the prepared substrate on both sides of the joint so both sides of 1/2 the tape are embedded into the adhesive on a width of at least 1 ” (38mm).  The layer thickness of the Adhesive should be approx. 0.08” (2.0mm).
2. The Tape is then immediately embedded into the fresh adhesive and pressed onto the adhesive using  a hand roller or a similar suitable tool. Ensure the tape has good contact to the adhesive everywhere.
3.  Then a second layer of Adhesive is applied on top of the Tape so that the edges of the tape are  over coated on a width of min. 2” (50mm). Also, apply Adhesive so that it covers the substrate next  to the tape on a width of at least 3/4" (19.0mm).

DIMENSIONS & PACKAGING

25 meter roll length, 1 and 2 mm thickness.

150,200,300,400,500,600 MM width rolls available. (perforated & unperforated)

Customization optional for bulk quantity.
